DORMER M900 SCREW EXTRACTOR M45-M50

DORMER M900 SCREW EXTRACTOR M45-M50

Stock Code: DORM9009
Delivery in 2-3 Working Days
£70.93 (exc VAT) per Each
Quantity: - +

The Dormer M900 Screw Extractors can be used counter-clockwise to remove broken right-handed bolts & screws from threaded holes without damaging threads. It’s necessary to drill a guide hole of proper size before using the extractor.

1 x Dormer M9009 Screw Extractor M45-M50

Specifications:

Bolt Size: M45 - M50
Drill Size for Low/Medium Tensile Screws: 27mm
Drill Size for High Tensile Screws (+75 tons/sq.inch): 28mm

Bolt Size Imperial: 1.3/4 - 2.1/8in
Drill Size for Low/Medium Tensile Screws: 1.1/16in
Drill Size for High Tensile Screws (+75 tons/sq.inch): 1.3/32in

Cutting Diameter Step: 24.61mm
Cutting Diameter Second Cutting Step (DC_2): 32.3mm
Clamping Width (WSC): 24.6mm
Clamping Length (LSC): 22.6mm

Overall Length (OAL): 121.3mm
Net Weight: 640g.

No detailed specifications are available for this product.

There are no downloads for this product.
